Simultaneous Nadir Overpasses (SNOs) Predictions
Prediction of SNOs between NPP and PACE Satellite Orbit:
Table of predicted SNOs for the next 14.0 days since TLE Epoch: 8/10/2026
| Index | Date (NPP) | Time (NPP) | Lat,Lon (NPP) | SZA (NPP ) | Date (PACE) | Time (PACE) | Lat,Lon (PACE) | SZA (PACE ) | Distance(km) | Time Diff (sec) |
| 1 | 08/10/2026 | 10:55:43 | -80.66, 150.72 | 111.80 | 08/10/2026 | 10:55:55 | -80.65, 150.79 | 111.82 | 1.50 | 12 |
| 2 | 08/12/2026 | 15:22:11 | -80.65, 84.34 | 111.20 | 08/12/2026 | 15:21:56 | -80.65, 84.36 | 111.20 | 0.47 | 15 |
| 3 | 08/14/2026 | 18:57:57 | 80.68,-150.14 | 69.53 | 08/14/2026 | 18:58:49 | 80.69,-150.26 | 69.53 | 2.33 | 52 |
| 4 | 08/14/2026 | 19:48:38 | -80.61, 18.29 | 110.64 | 08/14/2026 | 19:47:56 | -80.61, 18.22 | 110.61 | 1.19 | 42 |
| 5 | 08/16/2026 | 23:24:26 | 80.69, 143.10 | 70.23 | 08/16/2026 | 23:24:50 | 80.69, 143.19 | 70.20 | 1.70 | 24 |
| 6 | 08/17/2026 | 00:15:06 | -80.60, -48.11 | 110.01 | 08/17/2026 | 00:13:57 | -80.61, -48.27 | 109.94 | 3.23 | 69 |
| 7 | 08/19/2026 | 03:50:53 | 80.66, 77.01 | 70.83 | 08/19/2026 | 03:50:50 | 80.67, 76.94 | 70.84 | 1.45 | 3 |
| 8 | 08/21/2026 | 07:26:38 | -80.70,-157.61 | 108.38 | 08/21/2026 | 07:27:43 | -80.71,-157.72 | 108.40 | 2.11 | 65 |
| 9 | 08/21/2026 | 08:17:21 | 80.65, 10.57 | 71.50 | 08/21/2026 | 08:16:50 | 80.65, 10.65 | 71.50 | 1.62 | 31 |
| 10 | 08/23/2026 | 11:53:06 | -80.69, 135.97 | 107.70 | 08/23/2026 | 11:53:43 | -80.69, 136.00 | 107.73 | 0.75 | 37 |
Figure of NPP and PACE satellite orbits during SNOs since TLE Epoch: 8/10/2026
Download SNOs between NPP and PACE since TLE EPOCH: 08/10/2026 in txt file.
Historial Predications of SNOs between NPP and PACE
